Product features

Colour outer sheath

yellow

Area of Application

Structured cabling;Industrial Ethernet;Data center

Category

6A (TIA)

Type of connector connection 1

RJ45 8(8)

Type of connector connection 2

RJ45 8(8)

Connector type

RJ45 Standard yellow

Contacts

Gold plated

Pin assignment

1:1

Allocation

acc. TIA/EIA 568B

Type

Shielded

Length imprint

True

Anti-kink sleeve

plugged in

Colour anti-kink sleeve

yellow

Locking lever

True

Mating cycles

2000

Bending radius

>32.5 mm

Conductive shield

Selected shield contact

Suitable for degree of protection (IP)

IP20

Raw cable

Cat.7

Cable type

S/FTP

Cable construction

4×2

AWG-size

26/7

Conductor Material

Copper

Silicone-free

True

Jacket material

LSZH

Printing

Cat.7 raw cable S/FTP 4x2xAWG26/7 PIMF 600MHz ISO/IEC 11801 & EN50173-1 TIA/EIA 568B-2.1 Halogen Free ***10GIGABIT***

Outer diameter of the cable

6.5 mm

Flame-retardant

acc. IEC60332-1

Halogen-free

yes

Low smoke

acc. IEC61034

Temperature range

-20 – 60 °C

Impedance

100 ±5 Ω

Conductor resistance DC

146 Ω/km

Loop resistance

292 Ω/km

Resistance unbalance

5 %

Insulation resistance

10 MΩ

Contact resistance

30 mΩ

Test voltage

1000 V DC, 1min

POE class

PoE acc. to IEEE802.3af;PoE+ acc. to IEEE802.3at;4PPoE acc. to IEEE802.3bt

Current capacity

max. 1 A

Operating-/ tempering voltage

max. 50 V DC

Bandwidth

500MHz

Transmission

10Gbit

Connector

IEC 60603-7-51
