Product features

Category

6A (IEC)

Model

jack

Connection type

Insulation displacement connector

Type of connector

RJ45 8(8)

Screened

True

AWG-range for litz wire conductor

26 – 24

AWG-range

26 – 22

Special tool necessary

False

Suitable for round cable

True

Suitable for flat cable

False

Suitable for litz wire conductor

True

Suitable for solid core

True

Housing material

Zinc die cast

Dust cover

Yes

Complaint to UL94

V-0

For UAE suitable

False

Max. cable diameter

9.0 mm

Mating cycles

≥ 750

Contact coating

50 µ”

360° shield contact

True

Temperature range

-40 – 66 °C

Dielectric Withstanding Voltage

1000 V AC 60Hz

Current Rating

2 A

Insulation Resistance

≥ 500 MΩ

Contact Resistance

≤ 20 mΩ

4PPOE certified

True
