Açıklama
| Hardware Specifications | |
|---|---|
| Copper Ports | 8 x 10/100/1000BASE-T RJ45 auto-MDI/MDI-X port |
| SFP Slots | 2 x 100/1000BASE-X SFP interface Supports 100/1000Mbps dual mode and DDM |
| PoE Injector Port | 6 ports with 802.3at PoE+ injector function (Ports 1 to 6) 2 ports with 802.3bt PoE++ injector function (Ports 7 to 8) |
| Reset Button | > 5 sec: Factory default |
| LED Indicators | PWR, LNK/ACT, PoE-in-Use, LED Mode |
| Power Requirements | 100~240V AC, 50/60Hz, auto-sensing |
| Dimensions (W x D x H) | 280 x 229 x 44 mm, 1U height |
| ESD Protection | Contact Discharge 6KV DC Air Discharge 8KV DC |
| Enclosure | Metal |
| Weight | 1920g |
| Power Consumption/Dissipation | 280 watts (max.)/2013.2 BTU |
| Fan | 1 x smart fan Supports fanless mode |
| Switch Specifications | |
| Switch Architecture | Store-and-Forward |
| Switch Fabric | 20Gbps/non-blocking |
| Switch Throughput@64Bytes | 14.88Mpps |
| Address Table | 8K entries |
| Shared Data Buffer | 4.1 megabits |
| Flow Control | IEEE 802.3x pause frame for full duplex Back pressure for half duplex |
| Jumbo Frame | 10K bytes |
| Power over Ethernet | |
| PoE Standard | IEEE 802.3af/at PoE+ PSE (Ports 1 to 6) IEEE 802.3bt PoE++ PSE (Ports 7 to 8) |
| PoE Power Supply Type | End-span (Ports 1 to 6) End-span/Mid-span/802.3bt (Ports 7 to 8) |
| PoE Power Output | Ports 1 to 6: Per PoE+ port 54V DC, max. 30 watts Ports 7 to 8: 802.3bt mode, maximum 95 watts End-span mode: maximum 30 watts Mid-span mode: maximum 30 watts |
| Power Pin Assignment | End-span: 1/2 (-), 3/6 (+) Mid-span: 4/5 (+), 7/8 (-) 802.3bt: 1/2 (-), 3/6 (+), 4/5 (+), 7/8 (-) |
| PoE Power Budget | 240 watts with standard mode 100 watts with fanless mode |
| PoE Ability PD @ 12.5 watts | 8 units with standard mode 8 units with fanless mode |
| PoE Ability PD @ 25 watts | 8 units with standard mode 4 units with fanless mode |
| PoE Ability PD @ 51 watts | 2 units with standard mode 1 units with fanless mode |
| PoE Ability PD @ 71 watts | 2 units with standard mode 1 units with fanless mode |
| PoE Management Functions | |
| Active PoE Device Detection | Yes |
| PoE Power Recycling | Yes, daily or predefined schedule |
| PoE Schedule | 4 schedule profiles |
| PoE Extend Mode | Yes, max. up to 250 meters |
| PoE Port Management | Port Enable/Disable/Schedule PoE mode control 802.3bt 802.3at End-span 802.3at Mid-span Port Priority |
| Layer 2 Functions | |
| Port Mirroring | TX/RX/both Many-to-1 monitor Up to 4 sessions |
| VLAN | 802.1Q tag-based VLAN Up to 256 VLAN groups, out of 4094 VLAN IDs 802.1ad Q-in-Q tunneling Voice VLAN Protocol VLAN Private VLAN (Protected port) GVRP |
| Link Aggregation | IEEE 802.3ad LACP and static trunk Supports 2 groups of 2-port trunk |
| Spanning Tree Protocol | IEEE 802.1D Spanning Tree Protocol (STP) IEEE 802.1w Rapid Spanning Tree Protocol (RSTP) IEEE 802.1s Multiple Spanning Tree Protocol (MSTP) STP BPDU Guard, BPDU Filtering and BPDU Forwarding |
| IGMP Snooping | IGMP (v2/v3) snooping IGMP querier Up to 256 multicast groups |
| MLD Snooping | MLD (v1/v2) snooping, up to 256 multicast groups |
| QoS | 8 mapping IDs to 8 level priority queues Port number 802.1p priority 802.1Q VLAN tag DSCP field in IP packet Traffic classification based, strict priority and WRR |
| Ring | Supports ERPS, and complies with ITU-T G.8032 |
| Security Functions | |
| Access Control List | IPv4/IPv6 IP-based ACL/MAC-based ACL |
| Port Security | IEEE 802.1X – Port-based authentication Built-in RADIUS client to co-operate with RADIUS server RADIUS/TACACS+ user access authentication |
| MAC Security | IP-MAC port binding MAC filter Static MAC address |
| Enhanced Security | DHCP Snooping and DHCP Option82 STP BPDU guard, BPDU filtering and BPDU forwarding DoS attack prevention ARP inspection IP source guard |
| Management Functions | |
| Basic Management Interfaces | Web browser; Telnet; SNMP v1, v2c |
| Secure Management Interfaces | SSHv2, TLS v1.2, SNMP v3 |
| System Management | Firmware upgrade by HTTP/TFTP protocol through Ethernet network LLDP protocol SNTP PLANET Smart Discovery Utility PLANET NMS System and CloudViewer app |
| Event Management | Remote/Local Syslog System log |
| SNMP MIBs | RFC 1213 MIB-II RFC 1215 Generic Traps RFC 1493 Bridge MIB RFC 2674 Bridge MIB Extensions RFC 2737 Entity MIB (v2) RFC 2819 RMON (1, 2, 3, 9) RFC 2863 Interface Group MIB RFC 3635 Ethernet-like MIB RFC 3621 Power Ethernet MIB |
| Standards Conformance | |
| Regulatory Compliance | FCC Part 15 Class A, CE, LVD |
| Standards Compliance | IEEE 802.3 10BASE-T IEEE 802.3u 100BASE-TX/100BASE-FX IEEE 802.3z Gigabit SX/LX IEEE 802.3ab Gigabit 1000T IEEE 802.3x flow control and back pressure IEEE 802.3ad port trunk with LACP IEEE 802.1D Spanning Tree Protocol IEEE 802.1w Rapid Spanning Tree Protocol IEEE 802.1s Multiple Spanning Tree Protocol IEEE 802.1p Class of Service IEEE 802.1Q VLAN tagging IEEE 802.1x Port Authentication Network Control IEEE 802.1ab LLDP IEEE 802.3af Power over Ethernet IEEE 802.3at Power over Ethernet Plus IEEE 802.3bt Power over Ethernet Plus Plus IEEE 802.3az Energy Efficient Ethernet (EEE) RFC 768 UDP RFC 783 TFTP RFC 793 TCP RFC 791 IP RFC 792 ICMP RFC 2068 HTTP RFC 1112 IGMP v1 RFC 2236 IGMP v2 RFC 3376 IGMP v3 RFC 2710 MLD v1 RFC 3810 MLD v2 ITU G.8032 ERPS Ring |
| Environment | |
| Operating Temperature | 0~40 degrees C (Fanless mode enabled) 0~50 degrees C (Default) |
| Storage Temperature | -20 ~ 70 degrees C |
| Humidity | 5 ~ 95% (non-condensing) |
| Standard Accessories | |
| Packet Contents | Managed Switch x 1 QIG x 1 RS232 to RJ45 Console Cable x 1 Rubber Feet x 4 Rack-mounting Package x 1 Power Cord x 1 SFP Dust Caps x 2 |
