Öznur Kablo

Açıklama

Boyut ve Ağırlıklar				Elektriksel Bilgiler
Nominal Kesit	Dış Çap Yaklaşık	Net Ağırlık Yaklaşık	1000 m Kablo İçin Sevk Makara Ölçüleri	20 °C’ de İletken DC Direnci (Maks.)	Akım Taşıma Kapasitesi
Nominal Kesit	Dış Çap Yaklaşık	Net Ağırlık Yaklaşık	1000 m Kablo İçin Sevk Makara Ölçüleri	20 °C’ de İletken DC Direnci (Maks.)	Toprakta (A)	Havada (A)
mm²	mm	kg/km	cm	ohm/km	Toprakta (A)	Havada (A)
2×1.5 re	8,4	105	100	12,1	–	22
2×2.5 re	9,2	135	100	7,41	–	30
2×4 re	10,5	190	100	4,61	–	40
2×6 re	11,5	250	100	3,08	–	50
2×10 rm	15,3	400	1000	1,83	–	70
2×16 rm	17,5	550	1000	1,15	–	93
2×25 rm	21,0	780	1000	0,727	–	108
2×35 rm	23,0	1050	1000	0,524	–	135
3×1.5 re	9,0	120	100	12,1	–	22
3×2.5 re	10,0	160	100	7,41	–	30
3×4 re	11,0	220	100	4,61	–	40
3×6 re	12,5	300	100	3,08	–	50
3×10 rm	16,0	510	1000	1,83	–	70
3×16 rm	18,0	660	1000	1,15	–	93
3×25 rm	22,0	1050	1000	0,727	–	108
3×35 rm	24,5	1400	1000	0,524	–	135
4×1.5 re	9,5	140	100	12,1	–	18
4×2.5 re	10,5	190	100	7,41	–	24
4×4 re	12,5	290	100	4,61	–	32
4×6 re	14,0	380	100	3,08	–	42
4×10 rm	17,5	600	1000	1,83	–	60
4×16 rm	20,0	850	1000	1,15	–	80
4×25 rm	24,0	1275	1000	0,727	–	100
4×35 rm	27,0	1670	1000	0,524	–	124
5×1.5 re	10,0	167	1000	12,1	–	18
5×2.5 re	11,0	230	1000	7,41	–	24
5×4 re	14,0	350	1000	4,61	–	32
5×6 re	15,0	470	1000	3,08	–	42
5×10 rm	19,0	750	1000	1,83	–	60
5×16 rm	22,0	1100	1000	1,15	–	80
5×25 rm	27,0	1670	1000	0,727	–	100
5×35 rm	30,0	2300	1000	0,524	–	124

re : Tek telli iletken, rm : Bükülü iletken
