| Hardware Specifications | |
|---|---|
| Hardware Version | 3 |
| 10/100Base-TX Ports | 8 auto MDI/MDIX ports |
| LED Display | One for Power, One for Link / Act per port |
| Enclosure | Plastic |
| Dimensions (W x D x H) | 168 x 100 x 29 mm |
| Weight (g) | 152g |
| Power Requirements (External power adapter) | 5V DC, 1A |
| Power Consumption (100M Full operation) | 2.5 watts / 8.5 BTU |
| Switch Specifications | |
| Switch Processing Scheme | Store-and-Forward |
| Address Table | 1K |
| Share Data Buffer | 448k |
| Flow Control | Back pressure half duplex, IEEE 802.3x pause frame full duplex |
| Switch Fabric | 1.6Gbps |
| Throughput (packet per second) | 1.19Mpps |
| Maximum Packet Size | 1536bytes |
| Standards Conformance | |
| Standards Compliance | IEEE 802.3 (Ethernet) IEEE 802.3u (Fast Ethernet) IEEE 802.3x (Full-duplex Flow Control) |
| Regulation Compliance | FCC Part 15 Class B, CE |
| Environments | |
| Temperature | Operating: 0~50 degrees C Storage: -10~70 degrees C |
| Humidity | Operating: 5~95% Storage: 5~95% (non-condensing) |
